Air-cooled recycling lines RLVZ
It is used to process waste material into regranulate, especially HDPE and LDPE films. After processing by a grinding device (not part of the recycling line - see the section Small machines and accessories)
HS code
8432
No&Kind of standard
no standard
Product quality
1/3 ⭐
Product supply capacity
100 machines per month
Kind & number of packing
palette
Net weight
2600-3200 KG
Country of manufacture
Czech Republic
price
Description
Packaging machinery specifications
| Model: | RLVZ-90 | RLVZ-100 | RLVZ-110 | RLVZ-120 |
| Screw diameter: | 85mm | 95mm | 105mm | 115mm |
| Radius L/D: | 20:1 to 22:1 | 20:1 to 22:1 | 20:1 to 22:1 | 20:1 to 22:1 |
| Auger speed: | 10 – 100 rpm | 10 – 100 rpm | 10 – 100 rpm | 10 – 100 rpm |
| Main motor power consumption: | 18.5kW | 22 kW | 30 kW | 37 kW |
| Productivity: | 68 kg/h | 95 kg/h | 120 kg/h | 135 kg/h |
| Weight: | 2600 kg | 2800 kg | 3000 kg | 3200 kg |
| Dimensions: | 4000 x 1500 x 1800 mm | 4200 x 1500 x 1800 mm | 4400 x 1500 x 1800 mm | 4600 x 1500 x 1800 mm |
The delivery includes:
installation and training,
modification of the electrical installation in accordance with national regulations, including revision,
mechanical measures to prevent risks, including CE declaration of conformity,
service and warranty repairs provided by INDUSTRIAL MACHINERY sro and their service team.
